Explosion Proof 10 Ton Single Girder Overhead Crane pendant control

Brand Name : KUANGYUAN

Model Number : LB

Certification : CE ISO SGS GOST

Place of Origin : Henan, China (Mainland)

MOQ : 1 set

Price : Negotiation

Payment Terms : L/C, T/T, Western Union

Supply Ability : 35000 sets per year

Delivery Time : 35days

Packaging Details : Main girder and End beam-- packed by plastic woven cloth. Electrics-- packed by high quality plywood crate,

Equipment Feature : Explosion Proof

Lifting Weight : 10 ton

Lifting machanism : electric hoist

Color : Red

Control method : pendant control, remote control, cabin control

Material : Q235/Q345 steel plate

Power source : 3 Phase 380V 50hz

Explosion proof grade : Exd II BT4, Exd II CT4

Time of making : 2021

Contact Now

Explosion Proof 10ton Explosion Proof Single Girder Bridge Crane:
1. About Explosion Proof 10ton Explosion Proof Single Girder Bridge Crane
10ton Explosion Proof Single Girder Bridge Crane is one kind of light duty crane, It is characterized by more reasonable structure and higher strength steel as a whole. Used together with CD1 model, MD1 model, Hc model electric hoist as a complete set, it can be used in explosive environment to lift weight.
2. Advantages of our 10ton Explosion Proof Single Girder Bridge Crane
1. Lightweight structure, excellent performance, effectively improve space utilization.
2. Made of high quality steel, durable and corrosion resistant.
3. Complete standard configuration, stable operation, fast positioning, stable and safe operation.
4. Simple maintenance, low installation and maintenance costs, and long service life.
3.The technological parameter of 10ton Explosion Proof Single Girder Bridge Crane
Crane Travelling Device
Travelling speed (m/min)
20
30
45
60
75
Reducer ratio
58.95
39.42
26.38
19.37
15.88
Motor
Model
ZDY21-4
ZDR12-4
Power (kw)
2x0.8
2x1.5
Rotation (r/min)
1380
Lifting device

(Electric hoist)

And hoist travelling device
Electric Hoist model
CD1/ MD1
Lifting speed (m/min)
8, 0.8/8
Lifting height (m)
6, 9, 12, 18, 24, 30
Travelling speed (m/min)
20; (30)
Motor
Taper Squirrel-cage type
Work duty
A3- A5
Power supply
380V, 50Hz, 3-Phase
Wheel Diameter
270mm
Rail Surface width
37- 70mm

Explosion Proof 10 Ton Single Girder Overhead Crane pendant control
Company Information:
Henan Mine Crane Co., Ltd, located in crane hometown of China, is a share-holding industry enterprise with research, manufacturing and sales together. Our company supplies electric hoist, electric winch, single-beam crane, double-beam crane, bridge-type crane, grab basket crane, container crane, foundry crane, anti-explosion crane and European standard overhead crane, etc. Welcome your visit!
Explosion Proof 10 Ton Single Girder Overhead Crane pendant control
Customer Feed back:
Explosion Proof 10 Ton Single Girder Overhead Crane pendant control
FAQ:
Q: What kind of documents will be delivered together with the crane?
A: In general, there will be instruction manual, product certificate, technical specifications table, factory inspectionreport, the main part steel material reports, electrical diagrams, and crane general drawing, etc.
Q: Is it possible we visit the factory before order placed or inspect the cranes before delivery?
A: Sure, welcome to visiting our factory and this will helps us know more about each other.
Q: Due to the complication of factory situation, is it possible to send technician to our site so we can havethe most suitable crane solution?
A: Yes, it is okay, but the clilent needs to be responsible the round-trip tickets, visa, accommodation, meals, selt-security and salary per day abroad .
Q: For customs clearance documents, can you make special Co (Certificate of Origin), such as FORM E,China-Australia co, etc.?
A: Yes, if you need such documents, please kindly tell us in advance.
Q: What kind of installation support we can get from you?
A: If needed, we can send our engineers to your site to guide the installation and commissioning; Or we will supplyOnline inalllt guide, any isallatlon problems, we can confrm with our engineers, and help you to solve it.
