LDP 5tsingle girder overhead travelling crane 3P 220V 440V 50HZ 60HZ

  • 1
  • 2
  • 3

Brand Name : Kuangyuan

Model Number : LDP

Certification : CEI,SO

Place of Origin : China

MOQ : 1SET

Payment Terms : L/C, D/A, Western Union

Delivery Time : 30working days

Product Name : Low Cost Monorail Hoist LDP 1t 2t 3t Overhead Crane for Sale

Work Duty : A3

Main electrical parts : Schneider Brand

Power Source : 3P 220--440 V/50hz60HZ

Lifting mechanism : Eliectric Hoist

Control method : Ground Control+Remote Control+Cabin Control

Color : Customised

After-sales Service Provided : Engineers available to service machinery overseas

Lifting Speed : 0.8/5m/min

Motor : Cone Squirrel-cage Model

Contact Now

LDP 5tsingle girder overhead travelling crane 3P 220V 440V 50HZ 60HZ

Product Description:

LDP model EOT Single Girder Ovehead Crane is designed as light type lifting equipment according to China standard. It is equipped with the features of reasonable structure,max.lifting height, strong rigidity of whole set. This crane equips with wire rope electric hoist to lift different cargoes, its capacity can vary 1--20ton and span 7.5---31.5m, working class A3-A4 according to ISO standard.This kind of crane is widely used in factory, warehouse, stuff yard to lift goods, forbidden to use in flammable, explosive and corrosive environment (we have explosion proof and casting single girder crane for special condition). This single girder overhead crane is operated by pendent control or remote control.

Product Details

Product Structure:
Capacity(t) 1t, 2t, 3t, 5t 10t 16t
Span(m) 6.5m---28.5m
Lifting height(m) 3m---30m
Control mode Pendant control, wireless remote control, cabin control
Lifting speed(m/min) 2.8 ,8 , 8/0.8 2.3 , 5/0.8 7, 7/0.7 4, 4/0.4
Traveling speed(m/min) 20,30,45 (Inverter)
Service class(work grade) a) M2, M3: used in places of mild service, such as workshop and warehouse.
b) M4: used in places of Medium service such as assembly and depot.
Supply power(three phase power) 380V 50HZ 3Phase (according to user require)
Hoist type Wire rope or chain hoist, single or double speed
Working ambient temperature -20 °C~ <55°C.
Note It’s not suitable for lifting blazing & melting metal or toxicant as well as explosion-proof or insulating working conditions.

Security configuration:


1. Weight overload protection device
2. High-quality and durable polyurethane buffer
3. Crane stroke limit switch
4. Low voltage protection function
5. Emergency stop system
6. Current overload protection function

Certification:


Has passed CE, GOST, SGS, OHSAS&ISO9001: 2000 international quality control, ISO14001: 1996 environment, ISO9001: 2001 health and safety certification. Relying on the perfect quality control system, strict control system, strong production capacity and advanced testing methods, high output and high quality are guaranteed.

LDP 5tsingle girder overhead travelling crane 3P 220V 440V 50HZ 60HZ

LDP 5tsingle girder overhead travelling crane 3P 220V 440V 50HZ 60HZ
